Housing | Extruded Aluminum Profile |
Diffuser | Extrusion Diffuser |
Paint | Electrostatic Powder Paint |
Optics | Symmetrical |
Light Output Angle | 120° |
UGR Value | UGR ≤ 22 |
CRI | CRI ≥ 80 |
Color Bin Value | Mc Adams ≤ 3 |
Colour Options |
![]() ![]() ![]() |
Order Code | W/m | Lm | CCT | CRI | WxLxH (mm) | Kg | Technical Page | Photometric File |
---|---|---|---|---|---|---|---|---|
08131.05.30.007 | 7 | 675 | 3000 | Ra>80 | 21x515x22 | 0,25 | Technical Page | Ldt |
08131.05.40.007 | 7 | 725 | 4000 | Ra>80 | 21x515x22 | 0,25 | Technical Page | Ldt |
08131.10.30.014 | 14 | 1350 | 3000 | Ra>80 | 21x1015x22 | 0,40 | Technical Page | Ldt |
08131.10.40.014 | 14 | 1450 | 4000 | Ra>80 | 21x1015x22 | 0,40 | Technical Page | Ldt |
IP Rating | IP65 |
IK Rating | IK08 |
