STRIX
STRIX
09356
Min-Max Watt:
14-24 [W]
Lumen:
1600-4400 [lm]
Lumen / Watt:
180 [lm/W]
Technical Documents
Technical Page
STRIX
General Information
Housing
Corrosion Resistant Aluminum
Optics
PMMA Lens
Glass
Tempered Clear Glass
Paint
Electrostatic Powder Paint
Insulation Class
Class I
Product Dimensions [mm]
200(W)x100(H)x700(L)
Mounting Type
Surface
Electrical Info
Power
14-24W
Power Factor
>0.95
Light Source
High Power LED
Input Voltage
220-240V AC / 50-60 Hz
LED Driver
Constant Current
Ambient Temperature
-30°C / +60°C
LED Lifetime L70
>50.000 Saat
Cabling
Halojen-Free
Lighting Technology
UGR Value
UGR≤16
CRI [Ra]
CRI ≥ 80
Color Bin Value
Mc Adams ≤ 3
Optional
DALI / 1-10V
CRI>90 , 2700K~6500K , Tunable White
Emergency Lighting Unit

Order CodeWLmCCTWxHxL (mm)Technical PagePhotometric File
Space Solutions
Bank
Shopping Mall
Parking Lot
Metro - Airport
Education Institutions
