EXPLORA 2
07109
ATEX certified, designed for harsh environments.

Explora 2 is a professional lighting solution developed to provide safe and continuous lighting in industrial areas where there is a risk of explosive gas and dust atmospheres.

With its ATEX classification for Zone 2 and Zone 22 applications, robust aluminum housing, and high level of protection, it is suitable for demanding working conditions.

It is designed for use in production and process areas of industrial facilities where there is a risk of explosive gas or flammable dust.

  • Zone 2   Dusty environment
  • Zone 22 - Gaseous environment
Min-Max Watt:
26-65 [W]
Lumen:
3400-8200 [lm]
Lumen / Watt:
142 [lm/W]
Technical Documents
General Information
Zone 2
II 3G Ex nR IIC T6 Gc
Zone 22
II 3D Ex tc IIIC T95°C Dc
Housing
Aluminum Extrusion
Side Cover
Aluminum Injection
Diffuser
Silicone Sealed Extruded PC
Gasket
Transparent Silicone
Paint
Electrostatic Powder Paint
Insulation Class
Class I
Product Dimensions [mm]
59(W) x 87(H)
Mounting Type
Surface
Mounting Part
Stainless Spring Steel
Electrical Info
Power
26W-65W
Power Factor
>0.95
Light Source
SMD Mid Power LED
Cabling
Halogen-Free
Input Voltage
220-240V AC / 50-60 Hz
LED Driver
Constant Current
Ambient Temperature
-20°C / +50°C
LED Lifetime L70
>50.000 Hour
Lighting Technology
Light Output Angle
110°
UGR Value
UGR ≤ 22
CRI [Ra]
CRI ≥ 80
Color Bin Value
Mc Adams ≤ 3
Optional
DALI / 1-10V
CRI>90 , 2700K~6500K , Tunable White
Emergency Lighting Unit

Order CodeWLmCCTL (mm)KgTechnical PagePhotometric File
