Outdoor Lighting / Urban LightingXpoint
BACK
| Housing | Corrosion Resistant Aluminum Injection Body |
| Pole | Corrosion Resistant Galvanized Steel Body |
| Optics | PMMA Lens + Glass |
| Paint | Electrostatic Powder Paint |
| Optics | Symmetrical 60° / Asymmetrical 150° |
| Light Output Angle | Symmetrical 60° / Asymmetrical 150° |
| UGR Value | UGR ≤ 25 |
| CRI | CRI ≥ 80 |
| Color Bin Value | Mc Adams ≤ 3 |
| Colour Options |
 |
| Order Code | W | Lm | CCT | WxH (mm) | Productivity | Technical Page | Photometric File |
|---|---|---|---|---|---|---|---|
| 09591.73.30.036 | 28 | 3600 | 3000 | 700x3200 | 130 Lm/W | Technical Page | |
| 09591.73.40.036 | 28 | 3640 | 4000 | 700x3200 | 130 Lm/W | Technical Page | |
| 09591.73.30.075 | 58 | 7500 | 3000 | 700x4200 | 130 Lm/W | Technical Page | |
| 09591.73.40.075 | 58 | 7540 | 4000 | 700x4200 | 130 Lm/W | Technical Page | |
| 09591.73.30.110 | 85 | 11000 | 3000 | 700x5200 | 130 Lm/W | Technical Page | |
| 09591.73.40.110 | 85 | 11500 | 4000 | 700x5200 | 130 Lm/W | Technical Page | |
| 09591.73.30.150 | 116 | 15000 | 3000 | 700x6200 | 130 Lm/W | Technical Page | |
| 09591.73.40.150 | 116 | 15080 | 4000 | 700x6200 | 130 Lm/W | Technical Page | |
| 09591.13.30.072 | 2x28 | 2x3600 | 3000 | 1450x3200 | 130 Lm/W | Technical Page | |
| 09591.13.40.072 | 2x28 | 2x3640 | 4000 | 1450x3200 | 130 Lm/W | Technical Page | |
| 09591.13.30.150 | 2x58 | 2x7500 | 3000 | 1450x4200 | 130 Lm/W | Technical Page | |
| 09591.13.40.150 | 2x58 | 2x7540 | 4000 | 1450x4200 | 130 Lm/W | Technical Page | |
| 09591.13.30.221 | 2x85 | 2x11000 | 3000 | 1450x5200 | 130 Lm/W | Technical Page | |
| 09591.13.40.221 | 2x85 | 2x11500 | 4000 | 1450x5200 | 130 Lm/W | Technical Page | |
| 09591.13.30.301 | 2x116 | 2x15000 | 3000 | 1450x6200 | 130 Lm/W | Technical Page | |
| 09591.13.40.301 | 2x116 | 2x15080 | 4000 | 1450x6200 | 130 Lm/W | Technical Page |
| IP Rating | IP65 |
| IK Rating | IK08 |
Shopping Mall
Air Field
Parking lot
