Outdoor Lighting / ProjectorTitan-M
BACK
| Housing | Aluminum Injection |
| Glass | Tempered Clear Glass |
| Optics | PMMA Optical Lens |
| Paint | Electrostatic Powder Paint |
| Light Distribution | Symmetric - Asymmetric |
| UGR Value | UGR ≤ 22 |
| CRI | CRI ≥ 70 |
| Color Bin Value | Mc Adams ≤ 3 |
| Colour Options |
 |
| Order Code | W | Lm | Productivity | CCT | CRI | WxLxH (mm) | Kg | Technical Page | Photometric File |
|---|---|---|---|---|---|---|---|---|---|
| 09245.32.40.140 | 100 | 14000 | 140 lm/W | 4000 | Ra>70 | 386x320x63 | 4,4 | Technical Page | Ldt |
| 09245.32.40.175 | 125 | 17500 | 140 lm/W | 4000 | Ra>70 | 386x320x63 | 4,4 | Technical Page | Ldt |
| 09245.32.40.210 | 150 | 21000 | 140 lm/W | 4000 | Ra>70 | 386x320x63 | 4,4 | Technical Page | Ldt |
| IP Rating | IP66 |
| IK Rating | IK07 |
