Indoor Lighting / Industrial LightingForce-S
BACK
| Housing | Extruded Aluminum Profile |
| Side Cover | PC Injection |
| Reflector | UV Stabilized Lens + Heat Resistant Tempered Clear Glass |
| Paint | Electrostatic Powder Paint |
| Optics | Symmetric-Asymmetric |
| Light Output Angle | 30°,60°,90°,20x100° |
| UGR Value | UGR ≤ 22 |
| CRI | CRI ≥ 80 |
| Color Bin Value | Mc Adams ≤ 3 |
| Colour Options |
 |
| Order Code | W | Lm | CCT | CRI | L (mm) | Kg | Technical Page | Photometric File |
|---|---|---|---|---|---|---|---|---|
| 07308.4S.40.100 | 69 | 10500 | 4000 | Ra>80 | 445 | 3,5 | Technical Page | Ldt |
| 07308.4S.40.150 | 97 | 14700 | 4000 | Ra>80 | 445 | 3,5 | Technical Page | Ldt |
| 07308.6S.40.202 | 133 | 20000 | 4000 | Ra>80 | 595 | 5,1 | Technical Page | Ldt |
| 07308.7S.40.226 | 170 | 25400 | 4000 | Ra>80 | 745 | 6,6 | Technical Page | Ldt |
| 07308.8S.40.327 | 235 | 32800 | 4000 | Ra>80 | 845 | 7,5 | Technical Page | Ldt |
| 07308.1S.40.240 | 296 | 42000 | 4000 | Ra>80 | 1045 | 8,2 | Technical Page | Ldt |
| IP Rating | IP65 |
| IK Rating | IK08 |
Warehouse
Factory
Business Center
