Indoor Lighting / Spot LightingDrop
BACK
| Housing | Aluminum Injection |
| Frame | Aluminum Injection |
| Reflector | Metallized Surface Optical Reflector + Glass |
| Paint | Electrostatic Powder Paint |
| Optics | Symmetrical |
| Light Output Angle | 35° |
| UGR Value | UGR ≤ 22 |
| CRI | CRI ≥ 80 |
| Color Bin Value | Mc Adams ≤ 3 |
| Colour Options |
   |
| Order Code | W | Lm | Angle | CCT | CRI | ØxH (mm) | Cut-out dimensions (mm) | Kg | Technical Page | Photometric File |
|---|---|---|---|---|---|---|---|---|---|---|
| 05378.90.30.007 | 7 | 800 | 35° | 3000 | Ra>80 | 90x58 | Ø75 | 0,6 | Technical Page | Ldt |
| 05378.90.40.007 | 7 | 850 | 35° | 4000 | Ra>80 | 90x58 | Ø75 | 0,6 | Technical Page | Ldt |
| 05378.90.30.010 | 12 | 1180 | 35° | 3000 | Ra>80 | 90x58 | Ø75 | 0,6 | Technical Page | Ldt |
| 05378.90.40.010 | 12 | 1245 | 35° | 4000 | Ra>80 | 90x58 | Ø75 | 0,6 | Technical Page | Ldt |
| IP Rating | IP65 |
| IK Rating | IK03 |
Hospital
Business Center
Office
School
Restaurant
